“Model: AMXXW-10B
Capacity: Up to 70 racks per hour
4 programmes – 52, 75,180 plus continuous
Electric: 16.3kW (12.4kW booster), 400/50/3ph, 3 x 32 amps
Configurable to 10.1kW (6.2kW booster) 3 x 25amps
Standard features include:-
• Unique fully enclosed 4 sided insulated hood – eliminates the need for a ventilation canopy, saves energy, eliminates operator risk.
• ‘Intensiv’ unique three stage washing process incorporating Genius X² active filter system providing pre-wash, wash & rinsing functions!
• ‘ROTOR X’ wash system – 4 spoke arms delivers a powerful but balanced wash action
• Combi-filter with interlock prevents use of the machine if filters are not in place
• ‘Visiotronic’ single button control with text or symbols for ease of use plus cycle countdown, low salt & chemical warning and on demand temperature indication.
• Intelligent Soil Sensing optimises water usage depending on soil levels in the wash water
• Clip-In Wash & Rinse Arms allow quick & easy removal without fiddly screws or tools
• Hygiene Cycle actively removes tannin, starch and lime deposits from the wash tank, leaves the chamber clean machine with a fresh smell!
• ‘Ecotherm’ wash tank heating guarantees wash temp over 63*c for optimised washing efficiency
• ‘ACCURINSE’ low volume rinse using just 2.0ltrs per cycle combined with low capacity 40ltr wash tank reduces operating costs by up to 40%!
• USB Interface allows operational data (HACCP) to be downloaded in a report format
• Integral detergent and rinse aid dosing pumps with level sensing and low level indication
Plus:
o Smooth, counterbalanced hood lift movement with energy saving “park” position
o Large 440mm loading height allowing double racking
o Removable/hinged rack track – enables quick and easy removal of wash components for maximum hygiene.
o Integral drain pump and integral rinse booster pump for ease of installation
o Automatic self-flushing cycle when draining
o Class ‘AB’ type air gap
o Flexible hoses for connection to services
o 2 Plate Racks, 1 Cup Rack & 1 Cutlery Basket”
